Bus Cable

Bus Drop Cable

Bus Drop Cable

Bus Drop Cable is intended for use in indoor or outdoor applications for connection of stationary or portable equipment to facilitate relocation of equipment....

Send Inquiry
Product Details


Bus Drop Cable Applications:

It is intended for use in indoor or outdoor applications for connection of stationary or portable equipment to facilitate relocation of equipment. Rated for indoor and outdoor use in wet or dry locations.

Bus Drop Cable Compliances:

- OSHA acceptable

- RoHS Compliant

- UL Listed

- -20°C to 75°C - #14-#8

- -20°C to 60°C - #6-#2

Bus Drop Cable Conductor:

Fully annealed stranded bare copper per ASTM B-8 or ASTM B-172.

Bus Drop Cable Insulation:

Premium grade PVC

Bus Drop Cable Construction:

The conductors are insulated with Premium-grade, PVC insulation with a clear nylon jacket and are colored black, white, and red. The conductors and ground wires along with paper or polypropylene fillers are cabled for flexibility then wrapped with a mylar separator to aid strippability. The cable is covered with a gray PVC jacket.

Bus Drop Cable pecifications:

●Size: 14 AWG

●Number of Conductors: 3

●Conductor Strand: 19

●CGround Wires: 3 x 18

●Nominal Insulation Thickness: 0.030 inches

●Nominal Jacket Thickness: 0.045 inches

●Outside Diameter: 0.379 inches

●Ampacity: 20

●Net Weight: 0.111 lbs per ft

产品图片 Bus Drop Cable.jpg图标3.jpg



Production flow of Bus Drop Cable





1.What is your delivery date?

A:The delivery date is about 5-7 days after receipt of payment.

2.What are your payment terms?

A:30% deposit in advance and 70% balance before shipment.

3.Can you send free samples?

A:Yes, free samples are available; you just need to pay the shipping cost.图标7.jpg

Our usual packaging ways for Bus Drop Cable are as followings, OR it can be as customer's request.


Inquiry
Hot Tags: bus drop cable, manufacturers, suppliers, factory, wholesale, quotation, customized
